Features

1. The handle of circuit breaker amp is being sealable or equipped with padlock bracket avoids dangerous operation changes (ON/OFF).

2. The handle provides a clear indication of the contact position.

3. Adequate printing of all data on the front provides long-term identification.

4. Energy limiting class of circuit breaker switch: 3.

5. The emission of ionized gases is limited to the severest restrictions: 45 mm grid distance.

6. This circuit breaker amp for household in accordance with IEC60898 - B C and D tripping characteristics.

7. This MCB circuit breakers for industry in accordance with IEC60947-2 instantaneous tripping characteristics with release B: 4ln, release C: 8ln, release D: 12ln

8. This MCB mini circuit breakers may be extended with:

A wide range of RCDs

Full sets of additional components

Full sets of accessories

Functions

-Overload protection

-Short circuit protection

-Isolation -Controlling

Circuit breaker amp used in residential building, non-residential building, industry, energy infrastructure

Technical Specifications

Standard： IEC60898-1, IEC60947-2

Approvals: CE

Rated Current ln(A): 6,10,16,20,25,32,40,50,63

Rated Voltage Un: AC 230/400V DC 250V/500V

Rated Frequency (Hz): 50/60

Number Of Poles: 1,2,3,4

Tripping Characteristic: B,C,D

Characteristic Curve B (In): 3 - 5

Characteristic Curve C (In): 5 -10

Characteristic Curve D (In): 10 -20

Rated Switching Capacity Icn (A): 6000

Degree Of Protection: IP20, with connected conductors

Electrical Life(times): 6,000

Mechanical Life(times): 15,000

Breaking Capacity

Fire Resistance According To UL 94: V0

Mounting Position: Any

Cross-sections Of Wire (mm2) : 25

Terminal Tightening Torque (N.M) : 2.5

Working Environment Temperature(°C) : -40~ +50,max 95% humidity

Altitude (meters) : Max 2000

Tripping Characteristic Curves

• IEC60898-1 Standard

• Thermal Release

-The release is initiated by a bimetal strip in case of overload

-The standard defines the range of release of specific overload values

-Reference ambient temperature is 30°C

• IEC60947-2 STANDARD

• Thermal Release

-The release is initiated by a bimetal strip in case of overload

-The standard defines the range of release for two specific overload values -Reference ambient temperature is 30°C for LWBX

• Accessories Is Introduced
